HD-MB40


The Eliminator Lighting HD-MB40 heavy-duty motor is specially designed for large mirror balls. Supporting up to a 40-inch mirror ball or 89 pounds, the HD-MB40 will handle the full spectrum of mirror balls with no problem.

UPC: 810087371661SKU: MHD400

HD-MB40

AVAILABLE NOW FROM ELIMINATOR LIGHTING DEALERS
Designed to effortlessly handle mirror balls of various sizes, the Eliminator Lighting HD-MB40 heavy-duty motor ensures stability for mirror balls up to 39 inches and 89 pounds. Revel in the mesmerizing dance of light as the HD MB40KG motor rotates your mirror ball at a graceful 1-1.5 RPM, delivering that timeless mirror ball magic.
Crafted for indoor use, this professional-grade motor is your ticket to captivating nights at nightclubs, mobile entertainers' gigs, bands' performances, and permanent installations. With dimensions of 11.55" x 9.5" x 7.5" and a weight of 11.5 lbs., it's the epitome of power in a compact package.
Rest assured with its electrical prowess – AC 100-120V, 50/60Hz and a modest maximum power consumption of 7W. When you demand reliability, choose the ADJ HD MB40KG Heavy-Duty Pro Mirror Ball Motor for reliable performance for your large mirror balls.

HD-MB40

AVAILABLE NOW FROM ELIMINATOR LIGHTING DEALERS
Designed to effortlessly handle mirror balls of various sizes, the Eliminator Lighting HD-MB40 heavy-duty motor ensures stability for mirror balls up to 39 inches and 89 pounds. Revel in the mesmerizing dance of light as the HD MB40KG motor rotates your mirror ball at a graceful 1-1.5 RPM, delivering that timeless mirror ball magic.
Crafted for indoor use, this professional-grade motor is your ticket to captivating nights at nightclubs, mobile entertainers' gigs, bands' performances, and permanent installations. With dimensions of 11.55" x 9.5" x 7.5" and a weight of 11.5 lbs., it's the epitome of power in a compact package.
Rest assured with its electrical prowess – AC 100-120V, 50/60Hz and a modest maximum power consumption of 7W. When you demand reliability, choose the ADJ HD MB40KG Heavy-Duty Pro Mirror Ball Motor for reliable performance for your large mirror balls.

Specifications

SPECIFICATIONS:
• Heavy duty professional mirror ball motor
• For use with up to 40-inch (1M) mirror balls
• Max Load: 89lbs. (40kg)
• Indoor use only

ROTATION SPEED:
• 1-1.5 RPM (Not Adjustable)

SIZE/WEIGHT:
• Length: 11.55" (286 mm)
• Width: 9.5" (242 mm)
• Horizontal Height: 7.5" (191 mm)
• Weight: 11.5 lbs. (5.2 kg)

ELECTRICAL / THERMAL:
• AC 100-120V - 50/60Hz
• Maximum Power Consumption: 7W
• Ta = 25 Degrees Tb = 30 Degrees

Specifications are subject to change without notice.

Downloads

Filename Document type File type
HD-MB40 - User Manual User Manual PDF
